Trackgrip is designed for railway maintenance areas and construction sites.

Trackgrip


With its two-layer construction, extra-wide grid and excellent drainage, Trackgrip is the perfect defense against grease, grime and oil.

Made from non-porous PVC with a two-layer construction, Trackgrip is a grease-proof mat that’s impermeable to fluids and provides excellent drainage.

Its diamond-cut pattern provides the highest slip resistance, and the wide grid means it's the perfect walkway matting for environments where oils and greasy materials are present, like railroad maintenance areas, construction sites and processing plants.

Flexible format

Comes in 33' (10m) matting rolls

Quick installation

Roll out and cut to fit on site; contours to uneven surfaces

Simple to maintain

Easy to clean with a high pressure hose

Features + benefits

Features

Diamond Cut Pattern

Diamond cut pattern

Two Layer Construction

Two-layer construction and extra-wide spacing

Made From Non Porous PVC

Made from non-porous PVC

Comes In Rolls

Comes in 33' (10m) rolls

Made From Flexible PVC

Made from flexible PVC

Benefits

Slip Resistant

Certified slip resistant (DIN 51130: R11 ASTM 1677: 0.9/0.7)

Excellent Drainage

Excellent drainage (DIN 51130: V10)

Chemical Oil And Acid Resistant

Resistant to chemicals, acids, oils

Easy Installation

Quick to install

Easy To Clean

Easy to clean with a high pressure hose

Standard sizes
TrackgripTrackgrip Plus
Height5/8" (15mm)5/8" (15mm)
Standard roll options33' x 2’ (10 x 0.6m)33' x 2’ (10 x 0.6m)
33' x 3’ (10 x 0.91m)33' x 3’ (10 x 0.91m)
33' x 4' (10 x 1.22m)33' x 4' (10 x 1.22m)
Weight0.94lb/sq.ft (4.6kg/m2)0.94lb/sq.ft (4.6kg/m2)
Technical info
AcousticExcellent sound absorption
ChemicalResistant to most acids, alkalines and oils. You can read more about specific chemical resistances by downloading this information sheet.
CompositionFlexible Polyvinyl Chloride (PVC)
EnvironmentTrackgrip is 100% recyclable. When manufactured in black, it’s made using our post industrial recycled material. The recycled content averages at least 30%, but we strive for 100% wherever possible. We don’t use any substances included in the SVHC list under REACH in any of our matting products.
HygieneMade from non-porous PVC that’s naturally resistant to bacteria growth.
ReversionThermoplastic shrinkage can result in size reductions up to 2%. This may be accelerated in hot environments. You can read more about the causes of shrinkage by downloading this information sheet.
Slip resistance

ASTM E303 Dry/Wet with lines along–lines across 75-98 / 59-79
DIN 51130: R11, V10

ThermalDesigned to function at temperatures from -9°F and up to +140°F. Slight size variation may occur at temperature extremes.
UV lightResistant to PVC degradation
WarrantyThree years. Visit our policies page for more information about warranties.
Ancillaries
PVC edging (H: 9/16, W: 2 1/2")

PVC edging (H: 9/16, W: 2 1/2")


Supplied in rolls of 33’ (10.1m) length. One tube of cold welding paste recommended for every 33' of edging. Comes in black, dark gray, dark brown, holly green, Oxford blue, yellow. Size: 9/16" x 2 1/2" x 33' (14mm x 60mm x 10.1m)

Aluminum edging (H: 9/16")

Aluminum edging (H: 9/16")


Supplied in sections of 6'6" (2m) length with fixing screws and plugs. Comes in anodized aluminum and powder coated yellow. Size: 5/8" x 1 13 /16" x 6'6" (14mm x 45mm x 2m)

Small floor hook (H: 9/16")

Small floor hook (H: 9/16")


For securing sections of matting to the floor. Supplied in packs of 20 with screws and plugs

PVC edging (H: 9/16, W: 3 3/4")

PVC EDGING (H: 9/16, W: 2 1/2")


Supplied in rolls of 33’ (10.1m) length. One tube of cold welding paste recommended for every 33' of edging. Comes in black, dark gray, dark brown, holly green, Oxford blue, yellow. Size: 9/16" x 2 1/2" x 33' (14mm x 60mm x 10.1m)

Connector clips: dual purpose (H: 9/16")

CONNECTOR CLIPS: DUAL PURPOSE (H: 9/16")


For joining sections of matting together side-to-side or end-to-end. Supplied in packs of 10

Installation

Trackgrip's one-piece construction means installation is simple

  • Comes in 33' rolls, ideal for covering large areas
  • Quick and easy to cut to fit on site
  • No special tools needed
  • Contours to uneven surfaces

Cleaning

Keeping Trackgrip looking good is easy

  • Easy to handle
  • Roll or lift to clean
  • Simply clean with a high pressure hose
