Extreme weather conditions are no match for Gateway Brush (Frontrunner Brush), an extra aggressive entrance mat designed for external walkways and entrances exposed to extreme weather conditions.

SELECT A COLOUR:

The heavy-duty entrance mat’s brush inserts and open grid structure work together to scrape shoes clean, stopping ice, snow and dirt before it can be walked inside.

Integration is seamless – you can choose from surface-mounted or recessed walk-off mats – and the one-piece construction means you can cut to fit on site.

Seamless integration

Choose from modules with ramped PVC edging, rolls in standard widths and 10m lengths, or order a custom size

Simple installation

One-piece construction means you can cut to fit on site, with no previous site visits needed

Easy to maintain

Simply roll or lift to clean, no special tools needed

Download

Gateway Brush works as a standalone entrance mat, or you can pair it with a mat specifically designed for inside, like Gateway 14 Plus.

Features

Diamond Cut Pattern
Diamond cut pattern
Open Grid
Two layer, open-grid construction
Removes Moisture
Nylon brush inserts
Comes In Rolls And Modules
Comes in 10m (33') rolls or modules
Made From Flexible PVC
Made from flexible PVC

Benefits

High Soil Removal
Slip resistant, high soil removal
Excellent Drainage
Excellent drainage
Scrapes Shoes Clean
Scrapes shoes clean
Easy Installation
Seamless installation
Easy To Cut To Fit On Site
Easy to cut to fit on site, contours to uneven surfaces
Standard sizes
arrow_left [#335] Created with Sketch.



Gateway Brush

Height

14 - 19mm (9/16" - 3/44")

Standard roll options

10 x 0.6m (33' x 2’)

10 x 0.91m (33' x 3’)

5 x 1.2m (16'6" x 4’)

Standard module options

0.8 x 1.2m (2'7" x 4’)

1 x 1.5m (3'3" x 4’11")

1.1 x 2m (3'7" x 6’7")

Weight

12.7 kg/m2 (2.6 lb/sq.ft)


Surface modules are supplied with factory fitted PVC ramped edging to four sides.


Technical info
arrow_left [#335] Created with Sketch.

PVC GRID:


Acoustic

Excellent sound absorption.

Chemical

Resistant to most acids, alkalines and oils. You can read more about specific chemical resistances by downloading this information sheet.

Composition

Flexible Polyvinyl Chloride (PVC).

Environment

We don’t use any substances included in the SVHC list under REACH in any of our matting products.

Fire

EN ISO 13501-1:2007-Cfl-S2. Nylon brush fibres: UL94-V2

Reversion

Thermoplastic shrinkage can result in size reductions up to 2%. This may be accelerated in hot environments. You can read more about the causes of shrinkage by downloading this information sheet.

Thermal

Designed to function at temperatures from -23°C and up to +60°C. Slight size variation may occur at temperature extremes.

UV light

Resistant to PVC degradation.

Warranty

Two years. Visit our policies page for more information about warranties.


NYLON BRUSH INSERTS:

Construction

Aligned tufting

Bristle diameter

0.3mm

Insert thickness

12mm

Bristle content

Nylon 6.6 monofilaments

Bristle height

4.5mm

Backing

PVC

Ancillaries
arrow_left [#335] Created with Sketch.
For surface-mounted installations
PVC edging (H: 14mm, W: 60mm)

PVC edging (H: 14mm, W: 60mm)

Supplied in rolls of 10.1m (33') length. One tube of cold welding paste recommended for every 10m of edging. Comes in black, dark grey, dark brown, holly green, Oxford blue, yellow. Size: 14mm x 60mm x 10.1m (9/16" x 2 1/2" x 33')

PVC edging (H: 14mm, W: 100mm)

PVC edging (H: 14mm, W: 100mm)

Supplied in rolls of 10.1m (33') length. One tube of cold welding paste recommended for every 10m of edging. Comes in black, dark grey and yellow. Size: 14mm x 100mm x 10.1m (9/16" x 3 3/4" x 33')

Aluminium edging (H: 14mm)

Aluminum edging (H: 14mm)

Supplied in sections of 2m (6'6") length with fixing screws and plugs. Comes in anodised aluminum and powder coated yellow. Size: 14mm x 45mm x 2m (9/16" x 1 13 /16" x 6'6")

PVC snap track (H: 14mm)

PVC snap track (H: 14mm)

Two-part snap track that can be welded together to join rolls end-to-end or side-to-side to cover large areas. We recommend one tube of cold welding paste for every 10m of edging. Comes in black and dark grey. Size: 14mm x 2.5m (9/16" x 8'2")

For recessed installations
R frame (H: 14mm)

R frame (H: 14mm)

You'll need these to secure the matting on the left-to-right edges. Supplied in sections of 3m (10') length with fixing screws and plugs. Comes in anodised aluminum, powder coated dark grey and black. Size: 14mm x 12mm (9/16" x 15/32")

H section (H: 10mm)

H section (H: 14mm)

If the front-to-back dimension of the mat well is greater than the final width of your matting, you may need a H section to secure the different sections together. Supplied in sections of 3m (10') length, with fixing screws and plugs. Comes in black, with mat insert colour specified. Size: 14mm x 13mm (9/16" x 1/2").

J frame (H: 18mm)

J frame (H: 18mm)

Installing Gateway against a wall? You'll need a J frame to secure the matting on the left-to-right edges. Supplied in sections of 3m (10') length. Comes in dark grey and black. Size: 18mm x 60mm (11/16" x 2 3/8")

T frame (H: 14mm)

T frame (H: 14mm)

You can use a T frame (27mm) to divide the matting into sections left-to-right – this makes it easier to lift and clean. Supplied in sections of 3m (10') length with fixing screws and plugs. Comes in anodised aluminum, powder coated dark grey and black

TL frame (H: 14mm)

TL frame (H: 14mm)

You can use a T/L frame (55mm) to divide the matting into sections left-to-right – this makes it easier to lift and clean. Supplied in sections of 3m (10') length with fixing screws and plugs. Comes in anodised aluminum

L frame (H: 15mm)

L frame (H: 15mm)

Installing around a circular door or non rectangular space? You'll need a L frame to secure the matting. Size: 15mm x 2.7m length (5/8" x 8')

U section (H: 14mm)

U section (H: 14mm)

If the front-to-back dimension of the mat well is greater than the final width of your matting, you may need a U section to secure the different sections together. Supplied in sections of 3m (10') length, with fixing screws and plugs. Comes in anodised aluminum, powder coated dark grey and black. Size: 14mm x 19mm (9/16" x 3/4")

Installation

arrow_left [#335] Created with Sketch.

Cleaning

arrow_left [#335] Created with Sketch.

Keeping Gateway Brush looking good is easy

  • Reduces cleaning intervals
  • Simply roll or lift to clean
  • No special tools needed
  • Easy to clean using a vacuum, plus a coarse brush for clearing the debris in the grid


Watch our step-by-step guide to daily, weekly and monthly cleaning below.


BIM objects
arrow_left [#335] Created with Sketch.

Download our BIM objects in both Revit and IFC file types
