Standard sizes
| Crossgrip Line Covid-19 | |
| Height | 10.5mm (13/32”) |
| Standard roll options | 24 x 0.45m (80’ x 18”) |
| 24 x 0.6m (80’ x 2’) | |
| 24 x 0.91m (80’ x 3’) | |
| Weight | 4.8 kg/m2 (1 lb/sq.ft) |
Technical info
| Acoustic | Excellent sound absorption |
| Chemical | Resistant to most acids, alkalines and oils. You can read more about specific chemical resistances by downloading this information sheet. |
| Composition | Flexible Polyvinyl Chloride (PVC) |
| Environment | Crossgrip Line Covid-19 is 100% recyclable. When manufactured in black, it’s made using our post industrial recycled material. The recycled content averages at least 30%, but we always strive for 100%. We don’t use any substances included in the SVHC list under REACH in any of our matting products. |
| Drainage | DIN 51130: V10 |
| Fire | EN ISO 13501 - 1 : 2007 - Cfl - S1 |
| Hygiene | Made from non-porous PVC that’s naturally resistant to bacteria growth. |
| Reversion | Thermoplastic shrinkage can result in size reductions up to 2%. This may be accelerated in hot environments. You can read more about the causes of shrinkage by downloading this information sheet. |
| Slip resistance | ASTM F 1677 - Dry/Wet: 1.0/0.9 DIN 51130: R10 |
| Thermal | Designed to function at temperatures from -23°C and up to +60°C. Slight size variation may occur at temperature extremes. |
| UV light | Resistant to PVC degradation |
| Warranty | Three years. Visit our policies page for more information about warranties. |
Ancillaries
PVC edging (H: 10mm, W: 50mm)
Supplied in rolls of 10.1m (33’) length. One tube of cold welding paste recommended for every 10m of edging. Comes in black and dark grey. Size: 10mm x 50mm x 10.1m (3/8” x 2” x 33’)
PVC snap track (H: 10mm)
Two-part snap track that can be welded together to join rolls end-to-end or side-to-side to cover large areas.
We recommend one tube of cold welding paste for every 10m of edging. Comes in dark grey. Size: 10.5mm x 2.5m (13/32”x 8’2”).
Connector clips: dual purpose (H: 14mm)
For joining sections of matting together side-to-side or end-to-end. Supplied in packs of 10
Installation
Crossgrip Line’s one-piece construction means installation is simple:
- Loose lay, no fixing required
- Durable, one-piece construction
- Supplied in up to 24m rolls; place and unroll
- Easy to move if needed
Cleaning
Keeping Crossgrip Line looking good is easy:
- Simply lift or roll to clean
- Easy to clean with a high pressure hose
